Dimension
Range
|
| Magnetic
Strip by Injection
|
Width
=2mm~40mm |
| Thick
=1mm~8mm |
| Length
<=60M Roll |
|
Magnetic
Sheet by Compression
|
Length
<=800mm |
| Width
<=610mm |
| Thick
=0.3mm~8.0mm |
|
Magnetic
Sheet Roll Form by Compression
|
Width
<=610mm |
| Thick
=0.5mm~2.0mm |
| Length
<=60M Roll |
|
Magnetization
Options
|
•
Unilateral multipolar
• Unilateral bi-polar
• Thru thickness |
|
|
Additional
information
|
|
Flexible
magnets don’t crack or break. Meanwhile the products can absorb
shock and sound, so it is good for dc-motor which requires low noise.
|
|
Anisotorpic
flexible magnet has magnetic properties higher than isotropic flexible
magnets (about 30% higher) mainly tailored for dc-motors or strong
holding applications. Isotropic flexible magnets are good for promotional,
advertising and educational purposes.
|
|
Dimension
and shape can be in large sheet, large roll, or any size customer
prefers. For tailor-made size mould fee ranges from one to several
hundred US dollars only.
|
|
Self-adhesive
backing is available.
|
|
Color
PVC-laminated flexible magnet available in sheet and roll forms.
|
|
Color
printing on flexible magnet is available (artwork printed on PVC
laminated on the magnet); can tailor cut to preferred shape.
|
|
| |
|
Magnetic
Properties
|
|
Material
|
Isotropic/
Anisotropic
|
Remanence
|
Coercivity
|
Intrinsic
Coercivity
|
Max.
Energy Product
|
|
Grade
|
Anisotropic
|
Br
(mT)
|
Br
(Gs)
|
bHc
(kA/m)
|
bHc
(Oe)
|
iHc
(kA/m)
|
iHc
(Oe)
|
(BH)
max (KJ/m)
|
(BH)
max (MGOe)
|
|
MR-7L
|
Isotropic
|
165
+/-10
|
1,650
+/-100
|
108
+/-8
|
1,350
+/-100
|
132+/-8
|
1,650
+/-100
|
5.2
+/-0.4
|
0.65
+/-0.05
|
|
MR-7H
|
Isotropic
|
170
+/-10
|
1,700
+/-100
|
112
+/-8
|
1,400
+/-100
|
136+/-8
|
1,700
+/-100
|
5.6
+/-0.4
|
0.70
+/-0.05
|
|
MR-10
|
Semi-aniso
|
220
+/-5
|
2,200
+/-50
|
136
+/-8
|
1,700
+/-100
|
160+/-8
|
2,000
+/-100
|
8.0
+/-0.4
|
1.00
+/-0.05
|
|
MR-12
|
Anisotropic
|
245
+/-5
|
2,450
+/-50
|
140
+/-8
|
1,750
+/-100
|
148+/-8
|
1,850
+/-100
|
11.2
+/-0.4
|
1.40
+/-0.05
|
|
MR-12BH
|
Anisotropic
|
247.5
+/-2.5
|
2,475
+/-25
|
168
+/-8
|
2,100
+/-100
|
224+/-8
|
2,800
+/-100
|
12.0
+/-0.4
|
1.50
+/-0.05
|
|
